drk109
item parameter
measuring range 10~2000kpa
pressure between platen >430 kpa
transmit hydraulic volume 95±5ml/ min
diaphragm resistance protruding height 10mm, 20-40 kpa
accuracy 1grade (resolution: 0.1 kpa)
value accuracy ±0.5%f.s
hydraulic system leak in the measurement of upper limit value,
1min pressure drop <10%pmax
sample clip ring size upper platen aperture dia. φ30.5±0.05mm;
upper platen aperture dia. φ33.5±0.05mm
power 220v±10% 50hz
dimension 530mm×360mm×550mm
weight 70kg
